XL1509 Step-Down Buck Converter Module – Adjustable Voltage
XL1509 Step-Down Buck Converter Module – Adjustable Voltage
XL1509 Mini Step-Down Buck Converter Module – Adjustable Output Voltage
The XL1509 Step-Down (Buck) Converter Module is a super-compact, high-efficiency voltage regulator designed for electronics hobbyists, engineers, and DIY enthusiasts. Whether you're powering microcontrollers, sensors, or other low-voltage electronics from a higher-voltage source, this tiny module delivers stable, adjustable output with impressive efficiency — all in a space-saving SMD package.
Key Features
- Wide Input Voltage Range: Accepts 4.5V to 40V DC input, making it compatible with a broad range of power sources
- Adjustable Output Voltage: Dial in your exact required output voltage with ease using the onboard potentiometer
- High Efficiency: Up to 96% conversion efficiency minimises energy waste and heat generation
- Super Mini & Compact Design: SMD package keeps your builds neat and space-efficient
- Wide Operating Temperature: Reliable performance from -45°C to +85°C — suitable for demanding environments
- No High-Concern Chemicals: Manufactured without hazardous substances for safer handling
- New Condition: Comes brand-new, ready to integrate into your project
Technical Specifications
| IC Chip | XL1509 |
| Input Voltage | 4.5V – 40V DC |
| Output Voltage | Adjustable |
| Efficiency | Up to 96% |
| Package Type | SMD |
| Operating Temperature | -45°C to +85°C |
| Application | Computer, Electronics, DIY Projects |
| Quantity | 1 Module |
| Condition | New |
Ideal For
- Arduino, Raspberry Pi, and microcontroller projects
- LED driver circuits and sensor power supplies
- Robotics and automation builds
- Computer modding and custom electronics
- Portable power regulation solutions
Made in Mainland China.
