ULN2803A Darlington Array SMD IC – High-Voltage High-Current Driver
ULN2803A Darlington Array SMD IC – High-Voltage High-Current Driver
ULN2803A Darlington Transistor Array – Reliable High-Voltage, High-Current Drive
The ULN2803A Darlington Transistor Array (SMD package) is a dependable eight-channel driver IC engineered for high-voltage and high-current switching applications. Whether you're working on relay drivers, stepper motor controllers, display panels, or embedded computer systems, this versatile chip delivers consistent performance in a compact surface-mount form factor.
Key Specifications
- Model: ULN2803A (2803 Darlington Array)
- Package: SMD (Surface Mount Device)
- Output Current Rating: 500 mA per channel
- Supply Voltage: Up to 50 V
- Operating Temperature Range: -40°C to +85°C
- Condition: Brand New
- High-Concern Chemicals: None
- Application: Computer systems, motor drivers, relay interfaces, and more
Made in Mainland China.
Why Choose the ULN2803A?
The ULN2803A integrates eight NPN Darlington transistor pairs in a single IC, allowing you to drive multiple high-current loads simultaneously from low-level logic signals (TTL, CMOS, PMOS). Its wide operating temperature range makes it suitable for both indoor and light industrial environments, while the SMD footprint keeps your PCB designs slim and efficient.
Ideal Applications
- Relay and solenoid drivers
- Stepper and DC motor control
- LED and lamp arrays
- Printer and display drivers
- Embedded microcontroller output expansion
- General-purpose high-current switching circuits
What's Included
- 1 × ULN2803A SMD Darlington Array IC
