TRRS 3.5mm Jack Breakout Module – Audio & MP3 DIY

TRRS 3.5mm Jack Breakout Module for Headphone, Audio & MP3 Projects

Break out every pin of a standard TRRS 3.5mm audio jack to convenient solder points with this compact SMD breakout module. Whether you're building a custom headphone circuit, wiring up a video feed, or prototyping an MP3 player, this module gives you clean, reliable access to Tip, Ring 1, Ring 2, and Sleeve — all in one tidy board.

Key Features

• TRRS Pinout: Full breakout of Tip, Ring 1, Ring 2, and Sleeve — supports stereo audio + microphone or composite video signals
• Standard 3.5mm Jack: Compatible with headphones, earbuds, AV cables, and MP3 accessories
• Wide Operating Range: Works from -20°C to +70°C for reliable performance in varied environments
• Rated Supply Voltage: 30V / 0.5A — suitable for low-voltage audio and signal circuits
• SMD Package: Compact surface-mount design, easy to integrate into custom PCB or breadboard builds
• Condition: Brand new

Specifications

What Can You Build With It?

This breakout module is a go-to component for electronics hobbyists and makers. Use it to:

• Add a headphone output to a custom audio amplifier
• Interface a TRRS headset (with mic) to a microcontroller project
• Split composite video + audio signals in AV applications
• Prototype MP3 player add-ons or portable audio circuits
