TB6560 TB67S109 Stepper Motor Driver Module 3A 32-Step
TB6560 TB67S109 Stepper Motor Driver Module 3A 32-Step
TB6560 / TB67S109 Stepper Motor Driver Module
Take precise control of your CNC, 3D printer, or automation project with this high-performance TB6560 / TB67S109 Stepper Motor Driver Module. Delivering up to 3A output current and 32-step microstepping subdivision, this compact SMD module gives you smooth, accurate motor movement with minimal vibration and noise. Compatible with popular NEMA 17 (42mm) and NEMA 23 (57mm) stepper motors, it's an ideal drop-in driver for a wide range of DIY electronics and automation builds.
Made in Mainland China.
Key Features
- Dual-chip design: TB6560 + TB67S109 for reliable, stable motor drive performance
- 3A output current – handles demanding stepper motor loads with ease
- 32-step microstepping subdivision – ultra-smooth motion control for precision applications
- Wide supply voltage range: 10V–35V DC for flexible power sourcing
- Compatible with 42mm (NEMA 17) and 57mm (NEMA 23) stepper motors
- Operating temperature: 0–80°C for robust, continuous use
- SMD package – compact footprint, easy PCB integration
- No high-concern chemicals – safer for your workspace and the environment
Technical Specifications
| Driver ICs | TB6560 + TB67S109 |
| Output Current | 3A |
| Microstepping | Up to 1/32 step subdivision |
| Supply Voltage | 10–35V DC |
| Operating Temperature | 0–80°C |
| Package | SMD Module |
| Quantity | 1 × Driver Module |
| Country of Origin | Mainland China |
What's in the Box?
- 1 × TB6560 / TB67S109 Stepper Motor Driver Module
Who Is This For?
This driver module is perfect for hobbyists, engineers, and makers working on CNC routers, laser engravers, 3D printers, robotic arms, pick-and-place machines, and any other project requiring precise stepper motor control. Whether you're upgrading an existing build or starting fresh, this module delivers the performance and flexibility you need.
Related Products You May Like
- Air Compressor Pressure Gauge 0-10/0-12/0-25 Bar | DIY Tool
- Electromagnetic Induction Tester – Coil & Circuit Fault Detector
Learn more: OSHA guidance on hand and power tools
Frequently Asked Questions
Q: Which stepper motors is this TB6560 TB67S109 driver module compatible with?
A: This stepper motor driver module is compatible with 42mm (NEMA 17) and 57mm (NEMA 23) bipolar stepper motors. It supports a wide supply voltage range of 10–35V DC and delivers up to 3A output current, making it suitable for most standard stepper motors used in CNC and 3D printing applications.
Q: What is 32-step microstepping subdivision and why does it matter?
A: Microstepping subdivision breaks each full motor step into smaller increments — up to 1/32 of a full step with this module. This results in smoother motor movement, reduced vibration, lower operating noise, and greater positional accuracy, which is especially important in precision CNC machining, engraving, and 3D printing projects.
Q: What power supply do I need for this stepper motor driver?
A: The module accepts a supply voltage of 10V to 35V DC. Choose a power supply within this range that can deliver sufficient current for your specific stepper motor. Always ensure your power supply can handle the combined current demands of all driver modules in your system.
Q: Can I use this module with Arduino or other microcontrollers?
A: Yes. The TB6560 / TB67S109 driver module is designed to interface with standard microcontrollers such as Arduino, Raspberry Pi, and similar platforms via step/direction/enable signals. Always verify pin voltage compatibility between your controller and the module before connecting.
