STM32H745ZIT6 STM32H745ZIT3 LQFP-144 MCU Chip

STM32H745ZIT6 / STM32H745ZIT3 LQFP-144 Microcontroller (MCU) Chip

The STM32H745ZIT6 / STM32H745ZIT3 is a high-performance dual-core ARM Cortex-M7 + Cortex-M4 microcontroller from the STM32H7 series, housed in a compact LQFP-144 package. Designed for demanding embedded applications, this MCU delivers exceptional processing power, generous memory, and a rich set of peripherals — making it an excellent choice for engineers, hobbyists, and electronics developers alike.

Made in Mainland China.

Key Features

• Dual-Core Architecture: ARM Cortex-M7 (up to 480 MHz) + ARM Cortex-M4 (up to 240 MHz) for parallel processing
• Package: LQFP-144 — industry-standard footprint for straightforward PCB integration
• Model Numbers: STM32H745ZIT6 & STM32H745ZIT3 (same die, different temperature grades)
• General Purpose Use: Suitable for a wide range of embedded control, signal processing, and connectivity applications
• International Standard Compliance: Meets global quality and protection standards
• High Peripheral Count: Includes ADCs, DACs, timers, UART, SPI, I2C, USB, Ethernet, and more
• Customizable: Available for custom configurations and procurement
• No High-Concern Chemicals: Compliant with hazardous substance restrictions

Specifications

What Can This MCU Be Used For?

The STM32H745 is a versatile workhorse suited for a broad spectrum of applications, including:

• Industrial automation and motor control
• Robotics and drone flight controllers
• Audio and digital signal processing (DSP)
• IoT gateway and connectivity hubs
• Medical-grade instrumentation and data acquisition
• Human-Machine Interface (HMI) displays
• High-speed data logging systems

Why Choose the STM32H745ZIT6 / ZIT3?

With its dual-core design, developers can assign real-time tasks to the Cortex-M4 core while running complex algorithms or OS-based tasks on the Cortex-M7 — all within a single chip. The standard LQFP-144 footprint means it's easy to prototype or integrate into existing PCB designs without major layout changes.
