10-Pack SN74AHC1G00DBVR SOT23-5 NAND Gate Logic IC 8mA
10-Pack SN74AHC1G00DBVR SOT23-5 NAND Gate Logic IC 8mA
10-Pack SN74AHC1G00DBVR SOT23-5 Single 2-Input NAND Gate ICs
Upgrade your electronics projects with this convenient 10-piece lot of SN74AHC1G00DBVR logic gate ICs. Housed in the compact SOT23-5 surface-mount package, these single 2-input NAND gate chips deliver reliable high-speed logic switching with an output current of 8mA. Ideal for hobbyists, engineers, and electronics enthusiasts working with low-voltage digital logic circuits.
Key Features
- IC Type: Single 2-Input NAND Gate (1-Way)
- Package: SOT23-5 Surface-Mount
- Output Current: 8mA
- Part Number: SN74AHC1G00DBVR
- Quantity: 10 pieces per lot
- Condition: Brand New
- High-Concern Chemicals: None
- Compatible with AHC-family logic designs — low-voltage, high-speed operation
What Is a NAND Gate IC?
A NAND (NOT-AND) gate is a fundamental digital logic component used in circuit design. The SN74AHC1G00DBVR is a single-gate device in Texas Instruments' AHC logic family, offering fast switching speeds and low power consumption in a tiny SOT23-5 footprint — perfect for space-constrained PCB designs.
Ideal Applications
- Digital logic circuit prototyping
- PCB design and SMD soldering practice
- Microcontroller signal conditioning
- Low-voltage logic level interfacing
- Consumer electronics repair and development
Product Details
Brand: NioCen | Package: SOT23-5 | Quantity: 10 pcs/lot | Made in Mainland China
Related Products You May Like
- Electromagnetic Induction Tester – Coil & Circuit Fault Detector
- Air Compressor Pressure Gauge 0-10/0-12/0-25 Bar | DIY Tool
Learn more: ENERGY STAR product efficiency guidance
Frequently Asked Questions
Q: What is the SN74AHC1G00DBVR and what does it do?
A: The SN74AHC1G00DBVR is a single 2-input NAND gate integrated circuit from the AHC logic family, packaged in a SOT23-5 surface-mount housing. It performs a fundamental NAND logic operation — outputting LOW only when both inputs are HIGH — making it essential for digital logic design, signal gating, and circuit control applications.
Q: Are these ICs compatible with standard 3.3V and 5V logic systems?
A: Yes. The AHC (Advanced High-Speed CMOS) logic family supports a wide supply voltage range, making the SN74AHC1G00DBVR compatible with both 3.3V and 5V logic systems. This makes it versatile for use with Arduino, Raspberry Pi, and other microcontroller platforms.
Q: What package type is the SN74AHC1G00DBVR and how do I solder it?
A: These ICs come in the SOT23-5 surface-mount package, which is a small 5-pin SMD component. They are best soldered using SMD reflow techniques, hot air rework stations, or careful fine-tip soldering iron work. A magnifier and fine solder wire are recommended for hand soldering.
Q: How many units are included in one purchase?
A: Each order includes 10 pieces (10 pcs/lot) of the SN74AHC1G00DBVR SOT23-5 NAND gate IC, giving you ample stock for prototyping and small-batch production runs.
