RTX 2060 Direct Heating BGA Reballing Stencil – N18E Series (TU104 / TU106)
Give your GPU rework a precise, professional edge with this direct-heating BGA reballing stencil, purpose-built for NVIDIA RTX 2060 and related N18E series chips. Whether you're a seasoned electronics technician or a dedicated hobbyist, this stencil delivers clean, uniform solder ball placement every time — cutting down rework time and improving board-level results.
Compatible GPU Models
- N18E-G0-A1
- N18E-G1-A1
- N18E-G2-A1
- N18E-G3-A1
- N18E-G3R-A1
- N18E-G2R
- N18E-G1-B-KD-A1
- TU104
- TU106
Key Features
- Direct Heating Design: Allows the stencil to be placed directly on the BGA chip during reflowing, ensuring accurate solder ball alignment without additional fixtures.
- High-Precision Laser Cut: Each aperture is laser-cut for tight dimensional tolerances, guaranteeing consistent solder deposit volume across all pads.
- Durable Stainless Steel Construction: Resists warping and heat deformation through repeated use, maintaining shape under standard soldering temperatures.
- BGA Package Compatible: Specifically designed for BGA (Ball Grid Array) chip formats commonly found in laptop and desktop GPU modules.
- New Condition: Ships brand new, individually packaged for safe delivery.
- No Hazardous Chemicals: Free of high-concern chemicals for a safer working environment.
What's in the Box
- 1 × Direct Heating BGA Reballing Stencil (N18E / TU104 / TU106 compatible)
Specifications
| Application | Computer / GPU BGA Rework |
| Type | Direct Heating BGA Stencil |
| Package Format | BGA |
| Condition | New |
| Hazardous Chemicals | None |
| Quantity | 1 Piece |
| Country of Origin | Made in Mainland China |
Related Products You May Like
- Electromagnetic Induction Tester – Coil & Circuit Fault Detector
- Air Compressor Pressure Gauge 0-10/0-12/0-25 Bar | DIY Tool
Learn more: OSHA on eye and face protection
Frequently Asked Questions
Q: What is a direct heating BGA reballing stencil and how does it work?
A: A direct heating BGA stencil is a precision-cut metal template placed directly on top of a BGA chip during the reballing process. Solder balls or paste are applied through the stencil's apertures, ensuring each pad receives a uniform amount of solder. Heat is then applied directly through or around the stencil, allowing the solder to reflow and form clean, correctly spaced balls. This method is faster and more accurate than manual reballing for high-density GPU packages like the RTX 2060 N18E series.
Q: Which RTX 2060 GPU chips is this stencil compatible with?
A: This stencil is compatible with all major N18E series GPU variants used in RTX 2060 laptops and boards, including N18E-G0-A1, N18E-G1-A1, N18E-G2-A1, N18E-G3-A1, N18E-G3R-A1, N18E-G2R, N18E-G1-B-KD-A1, as well as TU104 and TU106 chip architectures. Always verify your chip model before ordering to ensure a perfect fit.
Q: Can beginners use this BGA stencil for GPU rework?
A: While the stencil is designed for precision and ease of use, BGA rework requires a hot air rework station or reflow oven, proper flux, and solder balls of the correct diameter. Beginners are encouraged to practice on non-critical boards first and follow established reballing guides to achieve the best results with this stencil.
