MT6826S Magnetic Encoder Angle Sensor Module for Arduino
MT6826S Magnetic Encoder Angle Sensor Module for Arduino
MT6826S High-Precision Magnetic Encoder & Angle Measurement Sensor Module
Take your Arduino and robotics projects to the next level with the MT6826S Magnetic Encoder Sensor Module. Engineered for high-precision, high-speed angle measurement, this Hall-effect sensor delivers reliable and accurate rotational position data for makers, engineers, and hobbyists alike. Whether you're building a servo controller, robotic arm, motor feedback system, or CNC machine, this module provides the precision you need.
Made in Mainland China.
Key Features
- High Precision Angle Measurement: The MT6826S chip uses advanced magnetic induction (Hall sensor) technology to deliver precise, repeatable angle readings across a full 360° rotation.
- High-Speed Response: Designed for fast-moving applications — captures rapid positional changes without lag, making it ideal for motor encoders and servo systems.
- Analog Sensor Output: Outputs a clean analog signal, easy to interface with Arduino, STM32, ESP32, Raspberry Pi, and other microcontrollers.
- Contactless Magnetic Sensing: Uses non-contact Hall-effect technology for wear-free, long-lasting performance — no physical brushes or friction components.
- Compact & Breadboard-Friendly: Lightweight polymer construction with a clean PCB module layout, suitable for prototyping and embedded integration.
- Customizable: Supports custom configurations for specialized project requirements.
Specifications
- Sensor Type: Magnetic Sensor (Hall Effect)
- Output Type: Analog Sensor
- Chip: MT6826S
- Material: Polymer PCB
- Compatible With: Arduino, STM32, ESP32, Raspberry Pi, and more
- Country of Origin: Made in Mainland China
Ideal For
- Robotic arm and joint angle sensing
- Brushless DC motor position feedback
- CNC and 3D printer axis tracking
- Servo and stepper motor control systems
- DIY electronics and Arduino maker projects
Related Products You May Like
- Electromagnetic Induction Tester – Coil & Circuit Fault Detector
- Air Compressor Pressure Gauge 0-10/0-12/0-25 Bar | DIY Tool
- 360° Bicycle Chain Cleaner Tool | Bike Gear Cleaning Kit
Learn more: OSHA on eye and face protection
Frequently Asked Questions
Q: What microcontrollers is the MT6826S magnetic encoder sensor module compatible with?
A: The MT6826S magnetic encoder module is compatible with a wide range of popular microcontrollers including Arduino (Uno, Mega, Nano), STM32, ESP32, ESP8266, and Raspberry Pi. Its analog output makes interfacing straightforward with most development boards.
Q: How does the Hall-effect magnetic encoder measure angle?
A: The MT6826S uses Hall-effect magnetic induction technology to detect the position of a rotating magnet placed above the sensor. As the magnet rotates, the chip measures the change in the magnetic field and converts it into a precise angle value, all without any physical contact — ensuring durability and accuracy over time.
Q: Do I need any additional components to use this sensor module?
A: To use the MT6826S module, you will need a small diametrically magnetized magnet (typically 6mm diameter) placed on the rotating shaft above the sensor. The module itself includes the MT6826S IC on a ready-to-use PCB, so minimal additional wiring is required to get started with your Arduino or other microcontroller project.
