KJD17 5-Pin Pushbutton Electromagnetic Switch 120V 16A
KJD17 5-Pin Pushbutton Electromagnetic Switch 120V 16A
5-Pin Pushbutton Electromagnetic Switch KJD17 – 120V / 16A
The KJD17 5-Pin Pushbutton Electromagnetic Switch is a heavy-duty, plug-in magnetic switch engineered for dependable performance in large-scale power equipment, machine tools, and garden machinery. Operating at 120V / 16A with silver-nickel alloy contacts and a durable plastic housing, this switch is built for long-term industrial use with minimal maintenance.
Key Features
- Power-Off & Under-Voltage Protection: Built-in protection functions automatically cut power under abnormal voltage conditions, safeguarding your equipment.
- Easy Plug-In Installation: No complex wiring required — simply align the 5-pin connector and insert it into the corresponding position for quick, tool-free setup.
- High-Quality Mechanism: Engineered for smooth, consistent actuation and an extended service life, ensuring the switch operates reliably cycle after cycle.
- Quick-Disconnect Brake Function: Features a dedicated brake function that rapidly disconnects a pole, providing precise control over motor operation and enhancing overall safety.
- Wide Compatibility: Suitable for a broad range of applications including garden tools, woodworking machine tools, and large-scale industrial power equipment.
- Silver-Nickel Alloy Contacts: Reduces arcing and contact wear for consistent electrical conductivity over thousands of switching cycles.
Specifications
| Model | KJD17 |
| Number of Pins | 5-Pin |
| Operating Voltage | 120V AC |
| Current Rating | 16A |
| Contact Material | Silver-Nickel Alloy |
| Housing Material | Plastic |
| Color | Black |
| Country of Origin | Made in Mainland China |
Package Contents
- 1 × KJD17 5-Pin Pushbutton Electromagnetic Switch
Notes
- Actual color may vary slightly from on-screen images due to monitor brightness and ambient lighting conditions.
- Please allow for minor measurement tolerances in listed dimensions.
