HX3208 DIY FM Radio SMD Kit – Soldering Assembly Module
HX3208 DIY FM Radio SMD Kit – Soldering Assembly Module
HX3208 DIY FM Radio Module Kit – Soldering Assembly Project for Electronics Enthusiasts
Build your own FM radio from scratch with the HX3208 DIY FM Micro SMD Radio Module Kit. Powered by a monolithic FM integration circuit, this compact soldering project is ideal for electronics hobbyists, students, and makers looking to sharpen their circuit assembly skills. Made in Mainland China.
⚠️ Please Note: This kit is designed for electronics enthusiasts who have hands-on experience with circuit assembly and soldering. The kit is verified to be in good working condition before shipment. Successful assembly depends on the builder's skills and experience. Please read all product details carefully before purchasing.
Key Features
- Electric Tuning IC: Uses the HX3208 monolithic FM integration circuit for convenient, accurate, and highly sensitive FM signal reception
- Low Voltage Operation: Runs on just 1.8V–3.5V, making it energy-efficient and suitable for battery-powered builds
- Built-In Mute Circuit: Internal mute circuitry suppresses noise during tuning for a clean listening experience
- 70 KHz IF Technique: Employs a low-to-mid frequency 70 KHz intermediate frequency design, eliminating the need for a ceramic filter — simpler, more reliable circuit layout
- Compact & Lightweight: Micro SMD form factor makes it easy to integrate into small enclosures or portable builds
- Great Learning Tool: Perfect for practicing SMD soldering techniques and understanding FM radio circuit design
Technical Specifications
- Model: HX3208
- Type: FM Frequency Modulation Radio Module
- Operating Voltage: 1.8V – 3.5V
- Component Style: SMD (Surface Mount Device)
- IF Frequency: 70 KHz
- Condition: Brand New
- Country of Origin: Made in Mainland China
Package Includes
- 1 × HX3208 FM Frequency Modulation Micro SMD Radio Kit (all components for assembly)
Related Products You May Like
- Electromagnetic Induction Tester – Coil & Circuit Fault Detector
- Air Compressor Pressure Gauge 0-10/0-12/0-25 Bar | DIY Tool
- 18 Pc Basswood Carving Blocks – Whittling Wood Kit for Carvers
Learn more: OSHA on eye and face protection
Frequently Asked Questions
Q: Is the HX3208 FM Radio Kit suitable for beginners?
A: This DIY FM radio soldering kit is best suited for hobbyists and electronics enthusiasts who already have experience with SMD soldering and circuit assembly. Beginners may find it challenging without prior soldering practice. We recommend familiarizing yourself with SMD components before attempting assembly.
Q: What power source does the HX3208 FM module require?
A: The HX3208 FM module operates on a supply voltage of 1.8V to 3.5V. It is compatible with common coin cell batteries or small lithium batteries, making it great for compact, portable FM radio builds.
Q: Does this kit include all components needed for assembly?
A: Yes, the package includes 1 × HX3208 FM Frequency Modulation Micro SMD Radio Kit with all the components required for assembly. You will need your own soldering iron, solder, and basic tools to complete the build.
Q: What FM frequency range does the HX3208 module support?
A: The HX3208 uses a standard FM frequency modulation circuit designed for the commercial FM band (typically 87.5–108 MHz). The electric tuning mechanism allows for accurate and convenient station selection across the full FM spectrum.
