The HF JQX-105F-1 Series DC Relay is a robust, high-power relay designed for demanding switching applications in automotive systems, household appliances, and industrial control circuits. Available in three coil voltage variants — 5V (005D), 12V (012D), and 24V (024D) — this normally open (NO) relay delivers a reliable 30A contact load, making it ideal for high-current switching tasks.
Key Specifications
- Model: HF JQX-105F-1 (005D / 012D / 024D-1HS)
- Relay Type: Electromagnetic / Temperature Relay
- Contact Configuration: Normally Open (NO)
- Rated Contact Load: High Power – 30A
- Coil Voltage: DC 5V, DC 12V, DC 24V
- Maximum Voltage: ≤ 36V DC
- Power Source: DC
- Applicable Use: Automotive & Household Appliances
- Quantity: 1 piece per order
- Country of Origin: Made in Mainland China
Why Choose the JQX-105F-1?
- ✅ High Current Capacity: Rated for 30A – handles heavy loads with ease
- ✅ Multi-Voltage Compatibility: Choose 5V, 12V, or 24V to match your circuit
- ✅ Normally Open Design: Circuit remains open until the coil is energized, providing safe default-off operation
- ✅ Versatile Applications: Suitable for automotive electronics, home appliance control, industrial automation, and DIY projects
- ✅ Compact & Easy to Install: Drop-in replacement for standard JQX-105F-1 relay sockets
Applications
This relay is commonly used in:
- Automotive relay circuits (fans, pumps, lighting)
- Household appliance control boards
- DIY electronics and maker projects
- Industrial switching and control panels
- Temperature control systems
