H3BA-N8H Multifunctional Time Relay – Precise Timing for Any Application
The H3BA-N8H 8-Pin Multifunctional Time Relay is a CE-certified, general-purpose solid-state timing relay designed for industrial and DIY control systems. With a wide timing range of 1.2 seconds to 300 hours and compatibility with DC 12V, DC 24V, AC 110V, and AC 220V power supplies, this relay is an incredibly versatile solution for automated control circuits, machinery, HVAC systems, and more.
Key Features
- Model: H3BA-N8H
- Contacts: 2NO + 2NC (2 Normally Open, 2 Normally Closed)
- Pin Configuration: 8-Pin
- Timing Range: 1.2 seconds to 300 hours — highly adjustable for short or long-duration cycles
- Frequency: 50/60 Hz
- Compatible Voltages: DC 12V / DC 24V / AC 110V / AC 220V
- Dimensions: 48 × 48 mm compact panel-mount form factor
- Type: Multifunctional Solid State Time Relay
- Certification: CE Certified
- Application: General Purpose — suitable for industrial automation, control panels, timers, and more
- High-Concern Chemicals: None
Why Choose the H3BA-N8H?
This multifunctional time relay offers multiple selectable timing modes, making it ideal for engineers, electricians, and hobbyists who need reliable, repeatable timing control. The solid-state design ensures long operational life and stable performance. Its compact 48×48 mm size fits standard panel cut-outs, while the broad voltage range means it works seamlessly across a wide variety of global power standards.
Specifications at a Glance
| Parameter | Detail |
|---|---|
| Model | H3BA-N8H |
| Pin Count | 8-Pin |
| Contact Output | 2NO + 2NC |
| Timing Range | 1.2s – 300h |
| Supply Voltage | DC 12V, DC 24V, AC 110V, AC 220V |
| Frequency | 50/60 Hz |
| Panel Size | 48 × 48 mm |
| Certification | CE |
