CY7C68013A EZ-USB FX2LP Development Board & Logic Analyzer

EZ-USB FX2LP CY7C68013A USB Core Board & Logic Analyzer

Take your embedded systems and firmware development to the next level with this versatile EZ-USB FX2LP CY7C68013A USB Core Board. Designed for engineers, hobbyists, and students alike, this compact development board combines a high-speed USB interface with a built-in logic analyzer — giving you powerful protocol debugging and signal capture capabilities in one convenient package.

Whether you're developing firmware, reverse-engineering protocols, or learning about USB communication, this board's support for I2C, Serial (UART), and SPI interface modules makes it an indispensable tool on your bench. The Mini USB connector provides an easy plug-and-play connection to any computer.

Key Features

• Cypress CY7C68013A Chip — Industry-standard EZ-USB FX2LP microcontroller with built-in USB 2.0 engine running at full/high speed
• USB Logic Analyzer Function — Capture and analyze digital signals directly over USB with compatible open-source software
• Multi-Protocol Support — Built-in I2C, Serial (UART), and SPI interface modules for broad compatibility
• Mini USB Connector — Convenient and widely compatible connection to a host PC
• SMD Package — Compact, surface-mount design for reliable performance
• Wide Operating Temperature — Rated from -40°C to +85°C for use in demanding environments
• New Condition — Ships brand new, ready for immediate use
• Customizable — Supports custom firmware development via the EZ-USB SDK

Specifications

Who Is This For?

This board is ideal for electronics engineers, makers, firmware developers, and students who need an affordable, multi-function USB development and protocol analysis tool. Compatible with popular open-source logic analyzer software such as PulseView and sigrok.
