E3F M18 Photoelectric Proximity Sensor Switch NPN PNP 6-36VDC
E3F M18 Photoelectric Proximity Sensor Switch NPN PNP 6-36VDC
E3F Series M18 Photoelectric Proximity Sensor Switch
The E3F Series M18 Photoelectric Sensor Switch is a reliable, industrial-grade proximity sensor designed for precise, non-contact object detection in automation, manufacturing, and DIY electronics projects. With a wide operating voltage range of 6–36V DC and selectable NPN or PNP output, this sensor integrates seamlessly into a broad range of control systems and microcontroller setups.
Key Features
- Wide Detection Range: Adjustable sensing distance from 3 to 30 cm, suitable for a variety of detection applications.
- Flexible Output Options: Available in NPN and PNP output configurations to match your circuit requirements.
- Wide Voltage Compatibility: Operates on 6–36V DC, compatible with a wide range of power supplies and PLCs.
- M18 Threaded Body: Standard M18 form factor for easy panel mounting and integration into existing setups.
- Durable Plastic Housing: Lightweight yet robust plastic construction rated for CE and CCC certification.
- Non-Contact Sensing: Photoelectric technology enables object detection without physical contact, reducing wear and improving reliability.
- Fast Response: Linear sensor design delivers quick, consistent switching for high-speed applications.
Technical Specifications
| Model | E3F Series |
| Operating Voltage | 6–36V DC |
| Output Type | NPN / PNP |
| Detection Range | 3–30 cm |
| Thread Size | M18 |
| Material | Plastic |
| Certifications | CE, CCC |
| Country of Origin | Made in Mainland China |
What's Included
- 1 × E3F Series M18 Photoelectric Proximity Sensor Switch
Great Pairing Products
Looking for more tools and electronics for your projects? Check out our Air Compressor Pressure Gauge – DIY Tool and our Electromagnetic Induction Tester – Circuit Fault Detector to round out your workshop toolkit.
Learn more: OSHA guidance on hand and power tools
Frequently Asked Questions
Q: What is the detection range of the E3F M18 photoelectric sensor switch?
A: The E3F Series M18 photoelectric sensor switch offers an adjustable detection range of 3 to 30 cm, making it versatile for detecting objects at varying distances in automation and industrial applications.
Q: What is the difference between NPN and PNP output on this photoelectric sensor?
A: NPN output (sinking) connects the load between the output and the positive supply, while PNP output (sourcing) connects the load between the output and the negative supply. Choose the output type that matches your controller or PLC input requirements. Both versions operate on 6–36V DC.
Q: Is this sensor compatible with Arduino or Raspberry Pi projects?
A: Yes, the E3F photoelectric sensor can be used with microcontrollers like Arduino or Raspberry Pi. For 5V systems, use a voltage divider or logic-level shifter on the signal line, and ensure your power supply falls within the 6–36V DC operating range for the sensor itself.
Q: What does M18 mean for this proximity sensor?
A: M18 refers to the threaded barrel diameter of 18 mm. This is a standard industrial thread size that allows the sensor to be easily mounted using standard M18 mounting brackets, nuts, or panel cutouts.
