E-Bike Hall Effect Speed Sensor 502F / 3144 – PCB Board RPM Sensor for Electric Bike Controllers
Keep your electric bike's controller running accurately with this high-quality Hall Effect Speed Sensor (502F / 3144). Mounted directly on a compact green PCB board, this sensor detects magnetic field changes to deliver precise RPM and speed readings to your e-bike controller — ensuring smooth, responsive performance on every ride.
Whether you're replacing a worn-out sensor or upgrading your e-bike's drivetrain electronics, this drop-in compatible PCB sensor is a reliable, cost-effective solution for most standard electric bike controllers.
Key Features
- Model Compatibility: 502F & 3144 Hall Effect sensor types
- Function: Accurate RPM and speed signal detection for e-bike motor controllers
- PCB Form Factor: Compact green PCB board for easy installation and secure mounting
- High-Pressure Rated: Designed for reliable operation under demanding electrical conditions
- Direct Replacement: Compatible with a wide range of electric bike controllers using standard Hall sensor pinouts
- Package: 1 × PCB Hall Effect Speed Sensor
- Color: Green
What Is a Hall Effect Sensor?
A Hall Effect sensor detects changes in a magnetic field and converts them into an electrical signal. In electric bikes, it is used inside the motor or controller to monitor rotor position and RPM, allowing the controller to manage power delivery and speed with precision.
Who Is This For?
This sensor is ideal for e-bike mechanics, DIY electric bike builders, and riders who maintain their own controllers. It is a direct replacement for worn or faulty 502F or 3144 Hall sensors found in most brushless DC motor controllers.
Important Notes
- Please allow a 2%–3% dimensional tolerance due to manual measurement. Dimensions shown are for reference only.
- Actual product color may vary slightly from images due to differences in monitor display settings.
- Made in Mainland China.
