Achieve perfectly centered, precise holes every time with this heavy-duty Aluminum Alloy Hole Puncher Locator Jig. Designed for woodworkers, DIY enthusiasts, and hobbyists, this 90-degree centering drill guide ensures accurate alignment on hinges, dowels, cabinet hardware, and more — no measuring, no guesswork.
Made in Mainland China.
Key Features
- 90-Degree Precision Alignment: Ensures perfectly perpendicular holes for clean, professional results every time.
- Aluminum Alloy Construction: Lightweight yet durable body resists wear and holds tight tolerances during repeated use.
- 6 Interchangeable Drill Bushings: Includes 5mm, 6mm, 7mm, 8mm, 9mm, and 10mm bushings to accommodate a wide range of drill bit sizes.
- Centering Accuracy: Precisely aligns centerlines when drilling into wood, MDF, plywood, and similar surfaces.
- Hinged Hole Puncher Design: Locks securely in place for repeatable, consistent hole placement without slipping.
- Available in Red or Blue: Distinct colors for easy identification in a busy workshop.
- Compact & Portable: Easy to store in your toolbox or workshop apron for use on-site or at home.
Specifications
- Material: Aluminum Alloy
- Compatible Drill Bit Sizes: 5mm, 6mm, 7mm, 8mm, 9mm, 10mm
- Drill Guide Angle: 90 Degrees
- Color Options: Red, Blue
- Country of Origin: Made in Mainland China
Package Contents
- 1 × Drill Guide Jig
- 6 × Interchangeable Drill Bushings (5mm, 6mm, 7mm, 8mm, 9mm, 10mm)
Important Notes
- Actual color may vary slightly from product images due to monitor brightness and lighting conditions.
- Please allow for minor measurement deviations due to manual measuring methods.
