90° Aluminum Drill Guide Jig | 5–10mm Centering Hole Puncher
90° Aluminum Drill Guide Jig | 5–10mm Centering Hole Puncher
Aluminum Alloy 90° Centering Drill Guide & Hole Puncher Jig
Achieve perfectly centred, accurate holes every time with this heavy-duty Aluminum Alloy 90° Drill Guide Jig. Designed for woodworkers, DIY enthusiasts, and craftsmen, this locator jig keeps your drill bit aligned at a precise 90-degree angle — eliminating guesswork and wasted material. Whether you're drilling hinge holes, dowel joints, or cabinet hardware, this tool delivers consistent, professional results on every project.
Made in Mainland China.
Key Features
- Precision 90° Alignment: Built-in centering guide ensures your drill bit stays perfectly perpendicular to the work surface for clean, accurate holes.
- 6 Interchangeable Drill Bushings: Includes 5mm, 6mm, 7mm, 8mm, 9mm, and 10mm bushings to accommodate a wide range of drill bit sizes.
- Durable Aluminum Alloy Construction: Lightweight yet robust — resistant to wear and built to last through heavy workshop use.
- Versatile Use: Ideal for hinge hole drilling, dowel alignment, furniture assembly, cabinet making, and general woodworking.
- Available in Red or Blue for easy identification in your tool kit.
- Brand New & Unused — ready straight out of the box.
Specifications
| Material | Aluminum Alloy |
| Drill Bushing Sizes | 5 / 6 / 7 / 8 / 9 / 10 mm |
| Drill Angle | 90 Degrees |
| Colors Available | Red, Blue |
| Origin | Mainland China |
Package Contents
- 1 × Drill Guide / Hole Puncher Locator Jig
- 6 × Drill Bushings (5mm, 6mm, 7mm, 8mm, 9mm, 10mm)
Notes
- Actual color may vary slightly from images due to monitor brightness and lighting conditions.
- Please allow minor manual measurement deviations.
Related Tools You May Like
- Air Compressor Pressure Gauge 0–10/0–12/0–25 Bar | DIY Tool
- 18 Pc Basswood Carving Blocks – Whittling Wood Kit for Carvers
- Garden Pruner Shears – Secateurs for Bonsai & Fruit Trees
Learn more: OSHA on eye and face protection
Frequently Asked Questions
Q: What drill bushing sizes are included with the drill guide jig?
A: The package includes 6 interchangeable drill bushings in the following sizes: 5mm, 6mm, 7mm, 8mm, 9mm, and 10mm — covering the most common drill bit sizes used in woodworking and DIY projects.
Q: Is this drill guide suitable for beginners as well as experienced woodworkers?
A: Absolutely! The 90-degree centering drill guide is designed to make accurate hole drilling simple and repeatable, making it ideal for both beginners learning woodworking techniques and seasoned craftsmen looking for consistent, professional results.
Q: What materials can I use this drill guide on?
A: While this tool is primarily designed for woodworking applications such as cabinet making, furniture assembly, and hinge drilling, it can also be used on other workable surfaces where precise, centred hole placement is needed.
