ADS1256 24-Bit 8-Channel ADC Data Acquisition Module
ADS1256 24-Bit 8-Channel ADC Data Acquisition Module
ADS1256 24-Bit 8-Channel ADC Data Acquisition Module
Take your electronics projects to the next level with this high-precision ADS1256 24-bit, 8-channel Analog-to-Digital Conversion (ADC) Data Acquisition Module. Designed for engineers, hobbyists, and researchers who demand accurate signal measurement, this module delivers exceptional resolution and stable performance across a wide range of applications — from sensor interfacing to scientific instrumentation.
Key Features
- 24-Bit High Resolution: Capture ultra-fine analog signal differences with 24-bit conversion depth for maximum measurement accuracy.
- 8 Input Channels: Monitor up to 8 independent analog inputs simultaneously, ideal for multi-sensor setups.
- 5V Supply Voltage: Compatible with standard 5V logic systems, including Arduino, Raspberry Pi, and other microcontroller platforms.
- Wide Operating Temperature: Reliable performance from 0°C to 80°C, suitable for a range of lab and field environments.
- SMD Package Design: Compact surface-mount construction for easy integration into your existing PCB or breadboard setup.
- SPI Interface: Simple and efficient communication via SPI protocol for fast data transfer.
- No High-Concern Chemicals: Built with safety in mind — no hazardous substances in the design.
- Brand New Condition: Ships as a fresh, unused unit ready for immediate deployment.
Specifications
| Chip | ADS1256 |
| Resolution | 24-Bit |
| Input Channels | 8 |
| Supply Voltage | 5V |
| Operating Temperature | 0°C – 80°C |
| Package Type | SMD (Surface Mount Device) |
| Interface | SPI |
| Quantity | 1 Module |
| Condition | New |
What Can You Do With It?
This ADC module is perfect for a wide variety of electronics and data acquisition tasks, including:
- Reading temperature, pressure, and environmental sensors
- Data logging for scientific and research applications
- Industrial signal monitoring and automation projects
- Precision voltage and current measurement
- Interfacing with Arduino, Raspberry Pi, STM32, and other microcontrollers
Package Contents
- 1 × ADS1256 24-Bit 8-Channel ADC Data Acquisition Module
Made in Mainland China.
Looking for more tools and electronics for your projects? Check out our Electromagnetic Induction Tester – Coil & Circuit Fault Detector or the Air Compressor Pressure Gauge 0-10/0-12/0-25 Bar | DIY Tool.
Learn more: OSHA guidance on hand and power tools
Frequently Asked Questions
Q: What microcontrollers is the ADS1256 ADC module compatible with?
A: The ADS1256 24-bit ADC data acquisition module communicates via SPI protocol, making it compatible with a wide range of microcontrollers including Arduino (Uno, Mega, Nano), Raspberry Pi, STM32, ESP32, and most other popular platforms that support SPI communication at 5V logic levels.
Q: How many analog channels can the ADS1256 module handle simultaneously?
A: The module features 8 single-ended or 4 differential analog input channels, allowing you to connect and read from multiple sensors or signal sources at the same time — making it ideal for multi-channel data acquisition and monitoring projects.
Q: What is the significance of 24-bit resolution in an ADC module?
A: A 24-bit ADC provides over 16 million discrete measurement levels, resulting in extremely fine resolution for analog signal conversion. This makes the ADS1256 module well-suited for precision measurement tasks where even tiny voltage variations need to be accurately captured and recorded.
