90×90mm Direct Heating BGA Reballing Stencil for RTX 2080 Ti TU102 GPU
Get precise, professional-grade BGA reballing results with this 90×90mm direct heating stencil designed specifically for the NVIDIA RTX 2080 Ti TU102-300A-K1-A1, 300-K3, and 300A-K2 GPU chips. Whether you're a professional electronics technician or an experienced hobbyist, this stencil delivers consistent solder ball placement every time — streamlining your GPU repair and rework workflow.
Made in Mainland China.
Key Features
- Compatible Models: TU102-300A-K1-A1 / 300-K3 / 300A-K2 — fits RTX 2080 Ti graphics cards
- Stencil Size: 90mm × 90mm — optimized for direct heating reballing stations
- Direct Heating Design: Allows solder balls to be applied directly without a separate fixture, saving time and improving accuracy
- High Precision Laser-Cut Holes: Ensures uniform, correctly sized solder ball placement across all BGA pads
- Durable Stainless Steel Construction: Resists warping and deformation under repeated heating cycles
- Condition: Brand new
- Quantity: 1 stencil per order
Who Is This For?
This BGA stencil is ideal for:
- Electronics repair technicians handling GPU reballing jobs
- PC hardware enthusiasts restoring failed RTX 2080 Ti cards
- Repair shops specializing in high-end graphics card rework
What Is a Direct Heating BGA Stencil?
A direct heating stencil is placed directly over the GPU chip and heated with a hot air station or infrared reflow tool. Solder balls are then rolled across the stencil, dropping into the precisely laser-cut holes to create a uniform ball grid array. This method is faster and more consistent than traditional reballing approaches and is widely preferred for complex chips like the RTX 2080 Ti TU102 series.
Compatible With
- NVIDIA GeForce RTX 2080 Ti (TU102-300A-K1-A1)
- TU102-300-K3
- TU102-300A-K2
Explore More Tools for Your Repair Bench
Looking to expand your toolkit? Check out these related products from our store:
- Electromagnetic Induction Tester – Coil & Circuit Fault Detector
- Air Compressor Pressure Gauge 0-10/0-12/0-25 Bar | DIY Tool
Learn more: OSHA on personal protective equipment
Frequently Asked Questions
Q: Is this BGA stencil compatible with all RTX 2080 Ti GPU variants?
A: This 90×90mm direct heating BGA stencil is specifically designed for TU102-300A-K1-A1, TU102-300-K3, and TU102-300A-K2 GPU chips used on NVIDIA RTX 2080 Ti graphics cards. Please confirm your exact GPU chip model before ordering to ensure compatibility.
Q: What equipment do I need to use this direct heating BGA stencil?
A: You will need a hot air rework station or infrared reflow station capable of reaching standard BGA soldering temperatures, along with appropriate solder balls (size 0.6mm is typical for RTX-series GPUs), flux, and a reballing fixture or PCB support. This stencil is designed for use by experienced repair technicians familiar with BGA rework procedures.
Q: How many stencils are included per order?
A: Each order includes one (1) BGA reballing stencil. It is a new item and is packaged in a standard BGA stencil envelope to protect it during shipping.
Q: Can this stencil be reused multiple times?
A: Yes. Thanks to its durable stainless steel construction, this direct heating stencil is designed to withstand multiple heating cycles without warping or distortion, making it a cost-effective tool for busy repair shops and technicians.
