90x90mm Direct Heating BGA Reballing Stencil for G84 & G86 GPU Series
Precision-engineered for professional BGA rework, this 90x90mm direct heating reballing stencil is compatible with a wide range of NVIDIA GPU chip models including G84-53-A2, G84-600-A2, G84-601-A2, G84-602-A2, G84-603-A2, G84-625-A2, G84-975-A2, G84-950-A2, and G86-303-A2. Ideal for electronics repair technicians, PCB rework professionals, and DIY computer repair enthusiasts who need accurate, repeatable solder ball placement.
Key Features
- Compatible Models: G84-53-A2 | G84-600-A2 | G84-601-A2 | G84-602-A2 | G84-603-A2 | G84-625-A2 | G84-975-A2 | G84-950-A2 | G86-303-A2
- Stencil Size: 90mm x 90mm – fits standard BGA reballing stations
- Direct Heating Design: Allows solder balls to be applied directly with hot air or IR reflow for fast, efficient reballing
- High-Precision Laser-Cut Holes: Ensures accurate solder ball alignment for reliable electrical connections
- Application: Computer GPU / graphics chip BGA rework
- Package Type: SMD-compatible
- Condition: Brand new
- Made in Mainland China
Who Is This For?
This stencil is a must-have tool for electronics repair shops, laptop motherboard technicians, and hobbyists performing GPU reballing on NVIDIA G84 and G86 series chips. Whether you're working on gaming laptops, workstations, or desktop graphics cards, this stencil delivers consistent results every time.
Related Products You May Like
- Electromagnetic Induction Tester – Coil & Circuit Fault Detector
- Air Compressor Pressure Gauge 0-10/0-12/0-25 Bar | DIY Tool
Learn more: OSHA on personal protective equipment
Frequently Asked Questions
Q: Which GPU chip models is this BGA reballing stencil compatible with?
A: This 90x90mm direct heating stencil is compatible with the following NVIDIA GPU models: G84-53-A2, G84-600-A2, G84-601-A2, G84-602-A2, G84-603-A2, G84-625-A2, G84-975-A2, G84-950-A2, and G86-303-A2. Always verify your specific chip model before ordering.
Q: What does "direct heating" mean for a BGA stencil?
A: A direct heating BGA stencil is designed to be placed directly on the chip during the reballing process, allowing a hot air gun or infrared reflow station to melt solder balls through the stencil openings for fast and precise ball placement — no separate flux frame or holder required.
Q: What solder ball size should I use with this stencil?
A: The recommended solder ball size depends on the specific chip model being reballed. For most NVIDIA G84 and G86 series GPUs, 0.45mm to 0.6mm solder balls are commonly used. Consult your chip datasheet or reballing guide for exact specifications.
Q: Is this stencil reusable?
A: Yes. With proper care — gentle cleaning after each use and careful storage — this stencil can be reused multiple times, making it a cost-effective tool for professional BGA rework.
