90x90 BGA Stencil Direct Heat – Intel i7/i5 11th Gen CPU Reballing

$10.56 $12.49

90×90mm Direct Heating BGA Reballing Stencil for Intel 11th Gen CPUs

Precision-engineered for professional motherboard repair technicians and electronics rework specialists, this 90×90mm direct heating BGA stencil is compatible with a wide range of Intel 11th Generation CPU models. Achieve clean, accurate solder ball placement every time without the need for a separate holder frame.

Compatible CPU Models

SRK02 – Intel Core i7-11390H
SRKSL – Intel Core i5-11320H
SRKSK – Intel Core i7-1195G7
SRKSB / SRKSC – Intel Core i5-1155G7
SRKSF – Intel Core i7-11375H

Key Features

Direct Heating Design: Apply heat directly through the stencil for faster, more efficient reballing — no separate holder required.
90×90mm Size: Standard professional size for easy use with most BGA reballing stations and fixtures.
High-Precision Laser Cut: Each aperture is precisely laser-cut to match the exact ball pitch of supported Intel CPUs, ensuring accurate solder ball transfer.
Durable Stainless Steel Construction: Built to withstand repeated high-temperature use in professional repair environments.
Condition: Brand new.

Package Contents

1 × 90×90mm BGA Reballing Stencil (Direct Heating)

Made in Mainland China.

Related Products You May Find Useful

Learn more: OSHA guidance on hand and power tools

Frequently Asked Questions

Q: Which Intel CPU models is this BGA stencil compatible with?

A: This 90×90mm direct heating BGA reballing stencil supports Intel 11th Gen CPUs including the i7-11390H (SRK02), i5-11320H (SRKSL), i7-1195G7 (SRKSK), i5-1155G7 (SRKSB/SRKSC), and i7-11375H (SRKSF).

Q: What does "direct heating" mean for a BGA stencil?

A: A direct heating BGA stencil allows the hot air or infrared heat to be applied directly through the stencil onto the solder balls during reballing. This eliminates the need for a separate holder frame, making the reballing process faster and more straightforward for repair technicians.

Q: What size is this BGA reballing stencil?

A: The stencil measures 90×90mm, which is a standard professional size compatible with most BGA reballing stations and fixtures used in laptop and computer motherboard repair.
