5V/12V Tilt Angle Sensor Relay Module SW520D for Arduino
5V/12V Tilt Angle Sensor Relay Module SW520D for Arduino
5V/12V 1-Channel Tilt Angle Sensor Relay Module with SW520D Ball Switch
Take your Arduino or DIY electronics project to the next level with this versatile 1-Channel Tilt Angle Sensor Relay Module. Featuring the golden SW520D ball switch, this compact SMD module detects tilt, slant, and orientation changes, then triggers a relay output — making it ideal for automation, robotics, security systems, and prototyping applications.
Key Features
- Dual Voltage Support: Compatible with both 5V and 12V supply voltages for flexible integration into a wide range of circuits.
- SW520D Gold Ball Switch: Reliable, sensitive tilt detection using a high-quality golden ball switch mechanism.
- 1-Channel Relay Output: Clean relay switching output (supports currents over 100mA) for controlling external loads.
- Wide Operating Temperature: Functions reliably from -40°C to +85°C, suitable for demanding environments.
- Arduino Ready: Plug-and-play compatibility with Arduino, Raspberry Pi, and other popular microcontroller platforms.
- SMD Package: Compact surface-mount design for easy integration into your PCB or breadboard setup.
- No Harmful Chemicals: Free from high-concern substances — safe for home lab and classroom use.
Specifications
| Supply Voltage | 5V / 12V |
| Channels | 1 |
| Sensor Type | SW520D Ball Tilt Switch |
| Output Type | Relay |
| Dissipation Power | Current >100mA |
| Operating Temperature | -40°C to +85°C |
| Package | SMD |
| Condition | New |
| Country of Origin | Made in China |
Ideal For
- Arduino & Raspberry Pi prototyping projects
- Tilt-triggered alarms and security systems
- Robotics and motion detection circuits
- DIY automation and smart home electronics
- Educational electronics and STEM kits
Related Products You May Like
- Electromagnetic Induction Tester – Coil & Circuit Fault Detector
- Air Compressor Pressure Gauge 0-10/0-12/0-25 Bar | DIY Tool
- 360° Bicycle Chain Cleaner Tool | Bike Gear Cleaning Kit
Learn more: OSHA on personal protective equipment
Frequently Asked Questions
Q: Is this tilt sensor relay module compatible with Arduino?
A: Yes! This 5V/12V 1-channel tilt sensor relay module is fully compatible with Arduino, Raspberry Pi, and most popular microcontroller platforms. Simply connect VCC, GND, and the signal pin, and you're ready to detect tilt and trigger relay outputs in your project.
Q: What is the SW520D ball switch, and how does it work?
A: The SW520D is a gold-plated ball tilt switch that detects changes in orientation or angle. When the module tilts beyond a threshold, the metal ball inside the switch shifts to make or break an electrical contact, which then triggers the relay output — making it perfect for tilt detection, anti-theft, and orientation-sensitive automation circuits.
Q: Can I use this module with a 12V power supply instead of 5V?
A: Absolutely. This module supports both 5V and 12V supply voltages, giving you the flexibility to integrate it into a wide range of electronic projects without needing additional voltage regulators.
Q: What load can the relay output handle?
A: The relay output on this module is rated for currents exceeding 100mA, making it suitable for switching small loads like LEDs, buzzers, motors, and other low-power devices in your DIY circuits.
