4-Channel MOSFET PWM Switch Controller Board DC 5V–27V
4-Channel MOSFET PWM Switch Controller Board DC 5V–27V
4-Channel MOSFET Pulse-Triggered Switch Controller Board with PWM & Optocoupler Isolation
Take full control of your DC motors, LED lighting strips, and other DC loads with this versatile 4-channel MOSFET switch controller board. Featuring built-in optocoupler isolation and PWM (Pulse Width Modulation) support, this module delivers reliable, noise-resistant switching performance across a wide voltage range of DC 5V to 27V — ideal for hobbyists, engineers, and electronics enthusiasts.
Key Features
- 4 Independent Channels: Control up to four separate DC loads simultaneously with individual pulse-triggered MOSFET switches.
- PWM Support: Smoothly adjust motor speed or LED brightness using Pulse Width Modulation signals for precise output control.
- Optocoupler Isolation: Each channel is isolated via optocoupler, protecting your microcontroller or signal source from voltage spikes and electrical noise.
- Wide Supply Voltage: Operates across a broad DC 5V–27V range, making it compatible with a wide variety of power sources and project setups.
- SMD Construction: Surface-mount design ensures a compact, low-profile board that fits easily into enclosures and DIY builds.
- Wide Operating Temperature: Rated for 0–200°C, suited for demanding environments.
- No High-Concern Chemicals: Board contains no high-concern chemical substances — safe for everyday electronics use.
- Customizable: Supports custom configurations to suit a variety of automation and control applications.
Specifications
| Channels | 4 |
| Supply Voltage | DC 5V – 27V |
| Package Type | SMD (Surface Mount Device) |
| Signal Type | Pulse-Triggered / PWM |
| Isolation | Optocoupler Isolated |
| Operating Temperature | 0 – 200°C |
| Quantity | 1 Module |
| Condition | New |
| Country of Origin | Made in Mainland China |
Typical Applications
- DC motor speed control (fans, pumps, actuators)
- LED strip and lighting dimming/switching
- Arduino, Raspberry Pi, and microcontroller-based automation projects
- Industrial control panels and DIY relay replacement
- TV and home electronics prototyping
Related Products You May Like
- Electromagnetic Induction Tester – Coil & Circuit Fault Detector
- Air Compressor Pressure Gauge 0-10/0-12/0-25 Bar | DIY Tool
- Clip-On Car Fan LED Display 199 Speeds | USB & Type-C
Learn more: OSHA on personal protective equipment
Frequently Asked Questions
Q: What voltage range does this MOSFET switch controller board support?
A: This 4-channel MOSFET PWM switch controller board supports a wide supply voltage range of DC 5V to 27V, making it compatible with most standard power supplies used in DIY electronics, automotive, and industrial control projects.
Q: Can I use this board with an Arduino or Raspberry Pi?
A: Yes! The board's optocoupler isolation allows it to interface safely with 3.3V or 5V microcontrollers such as Arduino and Raspberry Pi. Simply send a PWM or pulse signal from your microcontroller's GPIO pins to trigger each channel independently.
Q: What kinds of loads can this MOSFET controller board drive?
A: This module is well-suited for driving DC motors (fans, pumps, linear actuators), LED lighting strips, solenoids, and other DC resistive or inductive loads within the supported voltage range. Always check the maximum current rating of your specific MOSFET channels before connecting high-current loads.
Q: What is optocoupler isolation and why does it matter?
A: Optocoupler isolation uses light (LED + phototransistor) to electrically separate the control signal circuit from the load circuit. This protects your microcontroller or signal source from back-EMF, voltage spikes, and electrical noise generated by motors or other inductive loads, greatly improving reliability and safety in your project.
