20-Pack SN74LVC1G Series SOT23-5 Logic Gate ICs

Stock your electronics workbench with this versatile 20-piece assortment of SN74LVC1G series single-gate logic ICs in the compact SOT23-5 package. Sourced as original components, these chips cover the most commonly used single-gate logic functions — making them perfect for prototyping, PCB repairs, electronics projects, and production builds alike.

Included IC Variants

  • SN74LVC1G00DBVR – Single 2-Input NAND Gate
  • SN74LVC1G02DBVR – Single 2-Input NOR Gate
  • SN74LVC1G04DBVR – Single Inverter (NOT Gate)
  • SN74LVC1G07DBVR – Single Buffer / Driver (Open Drain)
  • SN74LVC1G08DBVR – Single 2-Input AND Gate
  • SN74LVC1G14DBVR – Single Inverting Schmitt Trigger

Key Features

  • ✅ Original components — genuine SN74LVC1G series ICs
  • ✅ SOT23-5 package — ultra-compact footprint ideal for space-constrained PCB designs
  • ✅ LVC logic family — Low-Voltage CMOS, operating from 1.65V to 5.5V
  • ✅ High-speed operation with low power consumption
  • ✅ Wide compatibility — 5V tolerant inputs on most variants for mixed-voltage systems
  • ✅ 20 pieces total — a practical multi-variant kit for prototypers and engineers

Typical Applications

  • Microcontroller & FPGA interface logic
  • Signal buffering and level shifting
  • Digital circuit design and prototyping
  • PCB repair and component replacement
  • Arduino, Raspberry Pi, and embedded systems projects
  • Mixed-voltage bus management

Product Details

  • Package Type: SOT23-5
  • Logic Family: LVC (Low-Voltage CMOS)
  • Quantity: 20 pieces (assorted variants)
  • Condition: Original / New
  • Made in: Mainland China

Related Products You May Like

Learn more: OSHA guidance on hand and power tools

Frequently Asked Questions

Q: What logic gate types are included in this SN74LVC1G SOT23-5 assortment kit?

A: This 20-piece kit includes six variants from the SN74LVC1G series: the SN74LVC1G00 (NAND), SN74LVC1G02 (NOR), SN74LVC1G04 (Inverter/NOT), SN74LVC1G07 (Open-Drain Buffer), SN74LVC1G08 (AND), and SN74LVC1G14 (Schmitt Trigger Inverter) — all in the compact SOT23-5 package.

Q: What supply voltage range do these SN74LVC1G ICs support?

A: The SN74LVC1G (Low-Voltage CMOS) series operates across a supply voltage range of 1.65V to 5.5V, making them suitable for both 3.3V and 5V digital systems, as well as mixed-voltage designs common in modern embedded and microcontroller applications.

Q: Are these original or counterfeit components?

A: These are listed as original SN74LVC1G series components manufactured in Mainland China. They are new, unused ICs intended for professional prototyping, PCB assembly, and electronics repair use.

Q: Can these logic gate ICs be used with Arduino or Raspberry Pi projects?

A: Yes. The SN74LVC1G series is widely used in Arduino, Raspberry Pi, and other embedded system projects for tasks such as signal buffering, logic inversion, Schmitt triggering for noise immunity, and interfacing between different voltage logic levels.
