125KHz RFID Reader Module RDM6300 – UART Output for Arduino & DIY Access Control
The RDM6300 125KHz RFID Reader Module is a compact, easy-to-integrate reader designed for hobbyists, makers, and engineers building custom access control, attendance tracking, or identification systems. With its standard UART output, it connects effortlessly to Arduino, Raspberry Pi, and other microcontroller platforms — no complex drivers required.
Whether you're prototyping a smart door lock, an inventory tag reader, or a DIY security system, this module delivers reliable 125KHz EM4100-compatible card and tag reading in a space-saving SMD form factor.
Made in Mainland China.
Key Features
- Frequency: 125KHz — compatible with EM4100, EM4102, and equivalent RFID cards & tags
- Output Interface: UART (TTL serial) — straightforward integration with Arduino, ESP8266, ESP32, STM32, and more
- Supply Voltage: 5V DC — powers directly from Arduino's 5V pin
- Low Power Consumption: Efficient design ideal for embedded and battery-assisted projects
- Compact SMD Package: Small footprint fits neatly into project enclosures
- Chip: RDM6300 — proven, widely documented chipset with extensive community support
- Condition: Brand new
- Customizable: Yes — suitable for custom PCB integration
Typical Applications
- DIY door access control systems
- Attendance and check-in tracking
- Arduino-based identification projects
- Inventory and asset tagging
- Smart home automation
- Robotics and maker projects
Technical Specifications
| Operating Frequency | 125KHz |
| Supply Voltage | 5V DC |
| Output | UART (TTL Serial) |
| Package | SMD |
| Compatible Tags | EM4100 / EM4102 and equivalents |
| Country of Origin | Mainland China |
