10pcs ISO1540D SOIC-8 2.5kVrms Bidirectional I2C Isolator IC
10pcs ISO1540D SOIC-8 2.5kVrms Bidirectional I2C Isolator IC
ISO1540D / ISO1540DR – 2.5kVrms Bidirectional I²C Isolator (Pack of 10)
Get reliable galvanic isolation for your I²C bus with this pack of 10 × ISO1540D / ISO1540DR ICs in the compact SOIC-8 package. Designed for engineers, makers, and electronics hobbyists who need robust two-way communication across an isolation barrier, these chips deliver up to 2,500 Vrms of isolation voltage, protecting sensitive microcontrollers and sensors from high-voltage transients and ground-loop interference.
Made in Mainland China.
Key Features
- Bidirectional I²C isolation – fully transparent SCL and SDA lines in both directions; no extra logic required
- 2.5 kVrms isolation voltage – robust galvanic barrier suitable for industrial and general-purpose designs
- SOIC-8 package (ISO1540D / ISO1540DR) – easy to solder, compatible with standard PCB footprints
- Supports I²C clock frequencies up to 1 MHz (Fast Mode Plus)
- Low propagation delay – maintains signal integrity for time-sensitive I²C transactions
- Wide supply voltage range – works with both 3.3 V and 5 V systems on either side of the isolation barrier
- General-purpose use – suitable for industrial automation, sensor isolation, medical instrumentation prototyping, motor drives, and more
- Pack of 10 – ideal for prototyping runs, small batch production, or stocking your component drawer
Specifications
| Model | ISO1540D / ISO1540DR |
| Package | SOIC-8 |
| Isolation Voltage | 2,500 Vrms |
| Interface | Bidirectional I²C (SCL + SDA) |
| Max Clock Frequency | 1 MHz (FM+) |
| Supply Voltage | 3.3 V / 5 V compatible |
| Quantity | 10 pieces per order |
| Origin | Mainland China |
Who Is This For?
Whether you're designing an industrial PLC interface, isolating a sensor from a noisy power bus, or building a prototype that demands electrically separated I²C segments, the ISO1540D delivers a drop-in, no-fuss solution. Its standard SOIC-8 footprint makes it straightforward to incorporate into new or existing PCB layouts.
